बॉयलर के लिए ASTM A213 T11 मिश्र धातु स्टील पाइप

Item

Cold rolled/Hot rolled alloy steel seamless pipe

Standard

ASTM A209M/ASME 209M, ASME SA210, ASTM A213/ASME SA213M

ASTM A333M/ASME SA333/SA333M, ASTM A334M/ASME SA334/SA334M

ASTM A335/ASME SA335, ASTM A519, ASTM A691

GB3087, GB6479-2000, GB9948-2006, GB5310-2013, GB5310-95, GB9948-88

DIN 17175, EN10216-2, JISG3467, JISG3458, JIS G3441, NF A49-213/215, BS3059, BS3604, BS3606

Materials

A209 T1/SA209 T1, A209 T1b/SA-209 T1b, A209 T1a/SA209 T1a.

T2, T5, T9, T11, T12, T22, T23, T24, T91, T911, T92, T122.

P1, P2, P5, P5b, P5c, P9, P11, P12, P21, P22, P23, P24, P91, P92.

4118, 4130, 4135, 4137, 4140.

20G, 25MnG, 15MoG, 15CrMoG, 20MoG, 12CrMoG, 12Cr2MoG, 12Cr1MoVG, 12Cr2MoWVTiB, 10Cr9Mo1VNb, 15CrMoG, 10CrMo910.

ST35.8, ST45.8, 15Mo3, 13CrMo44, 10CrMo910, 14MoV63,12Cr1MoV.

P195GH, P235GH, P265GH, 13CrMo4-5, 10CrMo9-10, 16Mo3, 10CrMo5-5, X10CrMoVNb9-1.

GRADE 91, CM65, CM70, CM75, CMSH70, CMS75, CMSH80.

GRADE 1/2 Cr, GRADE 1CR, GRADE 1 1/4 CR, 2 1/4 Cr, 3CR, 5CR, 9CR.

STPA12, STPA20, STPA22, STPA23, STPA24, STPA25, STPA26.

SCR420 TK,SCM415 TK, SCM418 TK, SCM420TK, SCM430TK, SCM435TK, SCM440TK.

TU15D3, TU13CD4-04, TU10CD910, TUZ10CD505.

S1-622-440, S2-622-440, S1-622-490, S2-622-490, S1-629-470, S2-629-470, S2-629-590.

HFS625 CFS625, CFS625.

Description

Surface

black painted, PE coated, galvanized

Length

5.8m, 6m, 11.8m, 12m, or as required

Wall Thickness

1-120mm

Outer Diameter

6-1200mm

Trade terms

Payment terms

T/T, L/C, D/P

Price terms

FOB, CIF

Package

Standard export seaworthy package or as required.

Delivery time

Prompt delivery or as the order quantity.

Export to

Alloy steel pipe applies to petroleum,chemical industry, electric power, boiler, high temperature resistant, low temperature resistant,corrosion resistant seamless steel pipe used.Alloy steel pipealso can made according to the customer.

Container size

20ft GP:5898mm(Length)x2352mm(Width)x2393mm(High) 24-26CBM

40ft GP:12032mm(Length)x2352mm(Width)x2393mm(High) 54CBM

40ft HC:12032mm(Length)x2352mm(Width)x2698mm(High) 68CBM

Contact

If you have any question,please feel free to contact me.

Grade

Chemical Composition%

C

Si

Mn

P, S Max

Cr

Mo

Ni Max

V

Al Max

T2

0.10~0.20

0.10~0.30

0.30~0.61

0.025

0.50~0.81

0.44~0.65

-

-

-

T11

0.05~0.15

0.50~1.00

0.30~0.60

0.025

1.00~1.50

0.44~0.65

-

-

-

T12

0.05~0.15

Max 0.5

0.30~0.61

0.025

0.80~1.25

0.44~0.65

-

-

-

T22

0.05~0.15

Max 0.5

0.30~0.60

0.025

1.90~2.60

0.87~1.13

-

-

-

T91

0.07~0.14

0.20~0.50

0.30~0.60

0.02

8.0~9.5

0.85~1.05

0.4

0.18~0.25

0.015

T92

0.07~0.13

Max 0.5

0.30~0.60

0.02

8.5~9.5

0.30~0.60

0.4

0.15~0.25

0.015

Grade

Chemical Composition%

Mechanical Properties

W

B

Nb

N

T. S

Y. P

Elongation

Hardness

T2

-

-

-

-

≥ 415MPa

≥ 205MPa

≥ 30%

163HBW(85HRB)

T11

-

-

-

-

≥ 415MPa

≥ 205MPa

≥ 30%

163HBW(85HRB)

T12

-

-

-

-

≥ 415MPa

≥ 220MPa

≥ 30%

163HBW(85HRB)

T22

-

-

-

-

≥ 415MPa

≥ 205MPa

≥ 30%

163HBW(85HRB)

T91

-

-

0.06~0.10

0.03~0.07

≥ 585MPa

≥ 415MPa

≥ 20%

250HBW(25HRB)

T92

1.50~2.00

0.001~0.006

0.04~0.09

0.03~0.07

≥ 620MPa

≥ 440MPa

≥ 20%

250HBW(25HRB)

Outside Diameter

OD Tolerance

WT Tolerance

Ovality Tolerance

Cut Length Tolerance

OD≤ 12, 7 mm

± 0, 13 mm

± 15 %

-

+ 3, 18 mm, - 0 mm

12, 7 mm < OD ≤ 38, 1 mm

± 0, 13 mm

± 10 %

max, 1, 65 mm

+ 3, 18 mm, - 0 mm

38, 1 mm < OD ≤ 88, 9 mm

± 0, 25 mm

± 10 %

max, 2, 41 mm

+ 4, 76 mm, - 0 mm

Standard

Steel grade

C

Si

Mn

P

S

Cr

Mo

Cu

Ni

V

Al

W

Ti

Nb

N

GB 3087

10

0.07-0.13

0.17-0.37

0.38-0.65

≤0.03

≤0.03

0.3-0.65

/

≤0.25

≤0.3

/

/

/

/

/

/

20

0.07-0.23

0.17-0.37

0.38-0.65

≤0.03

≤0.03

0.3-0.65

/

≤0.25

≤0.3

/

/

/

/

/

/

GB 5310

20G

0.17-0.24

0.17-0.37

0.38-0.65

≤0.03

≤0.03

≤0.25

≤0.15

≤0.2

≤0.25

/

/

/

/

/

/

20MnG

0.17-0.24

0.17-0.37

0.7-1.0

≤0.03

≤0.03

≤0.25

≤0.15

≤0.2

≤0.25

/

/

/

/

/

/

25MnG

0.22-0.3

0.17-0.37

0.7-1.0

≤0.03

≤0.03

≤0.25

≤0.15

≤0.2

≤0.25

/

/

/

/

/

/

15CrMoG

0.12-0.18

0.17-0.37

0.4-0.7

≤0.03

≤0.03

0.8-1.1

0.4-0.55

≤0.2

≤0.3

/

/

/

/

/

/

12Cr2MoG

0.08-0.15

≤0.5

0.4-0.7

≤0.03

≤0.03

2.0-2.5

0.9-1.2

≤0.2

≤0.3

/

/

/

/

/

/

12Cr1MoVG

0.08-0.15

0.17-0.37

0.4-0.7

≤0.03

≤0.03

0.9-1.2

0.25-0.35

≤0.2

≤0.3

0.15-0.3

/

/

/

/

/

12Cr2MoWVTiB

0.08-0.15

0.45-0.75

0.45-0.65

≤0.03

≤0.03

1.6-2.1

0.5-0.65

≤0.2

≤0.3

0.28-0.42

/

0.3-0.55

0.08-0.18

B0.002-0.008

/

10Cr9Mo1VNb

0.08-0.12

0.2-0.5

0.3-0.6

≤0.02

≤0.01

8.0-9.5

0.85-1.05

≤0.2

≤0.4

0.18-0.25

≤0.04

/

/

0.06-0.1

0.03-0.07

ASME SA210

SA210 A1

≤0.27

≥0.1

≤0.93

≤0.03

≤0.03

/

/

/

/

/

/

/

/

/

/

SA210 C

≤0.35

≥0.1

0.29-1.06

≤0.03

≤0.03

/

/

/

/

/

/

/

/

/

/

ASME SA213

SA213 T11

0.05-0.15

0.5-1.0

0.3-0.6

≤0.03

≤0.03

1.0-1.5

0.5-1.0

/

/

/

/

/

/

/

/

SA213 T12

0.05-0.15

≤0.5

0.3-0.6

≤0.03

≤0.03

0.8-1.25

0.44-0.65

/

/

/

/

/

/

/

/

SA213 T22

0.05-0.15

≤0.5

0.3-0.6

≤0.03

≤0.01

1.9-2.6

0.87-1.13

/

/

/

/

/

/

/

/

SA213 T23

0.04-0.1

≤0.5

0.1-0.6

≤0.03

≤0.03

1.9-2.6

0.05-0.3

/

/

/

≤0.03

1.45-1.75

/

0.02-0.08

≤0.04

SA213 T91

0.08-0.12

0.2-0.5

0.3-0.6

≤0.02

≤0.01

8.0-9.5

0.85-1.05

/

≤0.4

0.18-0.25

≤0.015

/

/

0.06-0.1

0.03-0.07

SA213 T92

0.07-0.13

≤0.5

0.3-0.6

≤0.02

≤0.01

8.5-9.5

0.3-0.6

/

≤0.4

0.15-0.25

≤0.015

1.5-2.0

/

0.04-0.09

0.03-0.07

DIN 17175

ST45.8-III

≤0.21

0.1-0.35

0.4-1.2

≤0.04

≤0.04

/

/

/

/

/

/

/

/

/

/

15Mo3

0.12-0.2

0.1-0.35

0.4-0.8

≤0.035

≤0.035

/

0.25-0.35

/

/

/

/

/

/

/

/

13CrMo44

0.0-0.18

0.1-0.35

0.4-0.7

≤0.035

≤0.035

0.7-1.1

0.45-0.65

/

/

/

/

/

/

/

/

10CrMo910

0.08-0.15

≤0.5

0.3-0.7

≤0.025

≤0.025

2.0-2.5

0.9-1.1

≤0.3

≤0.3

/

≤0.015

/

/

/

/
